Quick folding gate for high traffic frequency and limited space – pre-assembled for short installation times
The EntraQuick I is a compact quick folding gate designed for high-performance access points with frequent vehicle traffic. With opening speeds of up to 1 m/s, it ensures continuous traffic flow and noticeably reduces waiting times.
Its space-saving folding design requires no lateral run-back area, allowing installation even under constrained structural conditions. This keeps existing areas fully usable and minimizes structural modifications. Delivered pre-assembled, the system can be efficiently integrated and quickly commissioned.
The EntraQuick I is used wherever high-frequency access points need to be efficiently managed while making optimal use of available space. Its fast gate movement stabilizes traffic flow and prevents congestion, even with dense vehicle sequences. At the same time, the clearly guided gate operation ensures controlled and transparent access regulation.
Especially in confined site conditions, the folding design offers clear advantages over traditional sliding or swing gates, as no lateral run-back area is required. This makes the system suitable for both new developments and the modernization of existing access points where structural modifications should be kept to a minimum.
The pre-assembled delivery significantly reduces installation time and minimizes interruptions to ongoing operations. A manual emergency release ensures that access can still be opened in a controlled manner in the event of a power failure, maintaining operational capability at all times.
Smooth access control for high vehicle frequency and limited space availability
| Quick Folding Gate EntraQuick® I (double leaf) | |
| Gate height | 2050 mm and 2450 mm (incl. 100 mm ground clearance) |
| Clear width (CW) | 3000 mm – 6000 mm (in 500 mm increments) |
| Gate infill | Bar infill made of rectangular hollow section RHS 30×20 |
| Finish | Hot-dip galvanised (standard) Optional powder-coated |
| Weight | Approx. 650 kg (for maximum applicable dimension) |
| Lowered foundation | Top edge of foundation 200 mm below finished floor level |
| Operating speed | Max. 1.0 m/s; depending on clear width (CW) |
| Drive | Electro-mechanical in combination with joint mechanism |
| Locking | Self-locking; additional magnetic and bolt locks on request |
| Control unit | Automatic control (maintained command) WE-Tronic II with frequency converter |
| Emergency operation | By manual release of drive arm (during power failure) |
| Temperature range | Control unit: -10 °C … +50 °C; Drive: -45 °C … +50 °C |
| Optional add-ons | Serrated top edge, induction loops, traffic lights, LED spot lights, key safe, fence connection systems |
,,
Find the right protection for your needs.
The Quick folding Gate reaches opening speeds of up to 1 m/s. This reduces waiting times and supports efficient traffic flow, even with high vehicle frequency. The exact settings can be adjusted on a project-specific basis.
No. The folding design does not require a lateral run-back area. This allows installation even in confined access areas and ensures optimal use of available space.
The gate is delivered pre-assembled and can typically be installed within one day. The actual installation time depends on the structural conditions and the integration into existing control systems.
Yes. The system is designed for high-frequency access points and supports reliable operation under intensive use. The configuration is tailored to the specific requirements of each project.
Yes. A manual emergency release allows controlled opening even in the event of a power failure, ensuring that access can continue to be regulated.
The EntraQuick I is a Quick folding Gate designed for controlled access points with a focus on efficiency and space-saving performance. For certified high-security or anti-ram requirements, PeriGuard offers specialized security systems.
The product images shown are for illustrative purposes only and may vary in design and specific details.
